Whyte E-160 S MX Enduro

check size for availability
Check availability
  • Contact Us

The S-model e-160 has all the right elements to take your rides to the next level. Our unique lowered centre of gravity concept delivers class-leading handling and agility. And thanks to a huge 750Wh battery and high power 85Nm Bosch Performance Line CX motor, you're geared up for maximum enjoyment on the trails.

Our brand-new frameset adds a single-bolt release downtube protection system and tool-free battery removal to our legendary, multi award-winning low centre of gravity and Total Geometry handling. That gives it incredible agility and accuracy for dominating the rowdiest trails in twin 29er format or choose the 27.5in rear wheel MX version if you’re a shredder who really wants to get loose. XS and S sizes come with 27.5in wheels on both ends for balanced handling and all bikes get top-spec Maxxis tyres, oversized RockShox Zeb forks and 220mm front brake rotors for maximum confidence.

Because at Whyte we don’t cut corners, we just hit them as hard as possible.

Please note: our custom motor covers are not currently compatible with the aftermarket Bosch eBike Alarm and Connect module to add bike tracking and alarm functionality to your Smart System bike.

High Power - Low Centre of Gravity

The new 85Nm Performance Line CX drive unit and Bosch’s largest capacity 750Wh battery are positioned to give an ultra-low centre of gravity, delivering responsive and intuitive power with the most agile handling imaginable.

Tuned by the Fastest Racers

Our Senior Design Engineer Sam Shucksmith, the current and two-time British Enduro Series Champion is dedicated to researching and developing the ultimate suspension tune. He has set up the best, most optimised suspension performance for the e-160 to give you the best grip, confidence and control.


COLOURGloss Turquoise with Black & WhiteCASSETTEShimano CS-LG600, 11 speed, 11-50T
FRAME6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing, Shape.it Up Link and 12mm X 148mm Boost DropoutsCHAINShimano CN-LG500, 11 speed
FORKRockShox ZEB 29", 160mm Travel, 44mm Offset, DebonAir, Rush RC Damper, Fast Black Coating, Tapered Steerer, 110mm x 15mm Boost, Maxle UltimateCRANKSETWhyte, Forged Alloy, 165mm, direct mount 36T
REAR SHOCKRockShox Deluxe Select R, Fast Black Coating, Adjustable ReboundBOTTOM BRACKETN/A
HEADSETFSA No. 55R/35 Orbit 1.5 ZS, 1.8" Lower and 1 1/8" Upper Sealed Cartridge BearingsSEATPOSTWhyte drop.it Adjust, 30.9mm, M/L 140-170mm Travel, XL 170-200mm Travel, Paddle Remote Lever
REAR HUBAlloy, E-Bike Specific, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 32 HoleSADDLEWhyte Custom, Dual Density, Triple Panel Design
FRONT HUBAlloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 31mm Torque Caps, 32 HoleHANDLEBARWhyte Custom 6061 Alloy, 30mm Rise, 35mm Bar Bore, 780mm Wide
SPOKESDT Swiss New Champion 2.0mm, Black Stainless, Brass NipplesSTEMWhyte Enduro Stem, 35mm Bar Bore, 35mm Extension
RIMSWTB HTZ i30 TCS 2.0 System, Asymmetric, Sleeved Joint, Super Tough Construction, Tubeless Ready, 32 HoleGRIPSWhyte Lock-On Enduro Grip
TYREMaxxis Assigai WT, TR, 29" x 2.5" 120TPI, EXO+ Casing, 3C Maxx Grip, Dual Compound, Front, Maxxis Minion DHR II WT, TR, 27.5" x 2.4" 120TPI, Double Down, 3C Maxx Terra, Dual Compound, Folding Bead, RearBRAKES FRONTShimano Deore BL-M6100 4 piston caliper, with 220mm 6 bolt rotor
SHIFT LEVERSShimano M8130 Deore XT 11 speedBRAKES REARShimano Deore BL-M6100 4 piston caliper, with 203mm 6 bolt rotor
REAR MECHShimano M8130 Deore XT, Shadow Plus, direct mountPEDALSNone


A HEAD TUBE ANGLE 64.8 (64.2) 64.8 (64.2) 64.8 (64.2)
B SEAT TUBE ANGLE75.575.375.1
C TOP TUBE HORIZONTAL607.3640.4672.5
D BB HEIGHT ABOVE GROUND344 (336.2)344 (336.2)344 (336.2)
F WHEEL BASE1234.81269.21302.7
G CHAIN STAY LENGTH444.5444.5444.5
